Barcode Types and Functions
Barcode Symbology:
Global Standards One (GS1). As the name suggests, the organization can be considered primarily as the standards organization managing the assignment of various numbering schemes upon which global commerce has come to rely.
There are two basic bar codes:
Single Line Bar Code: holds information nicely in the horizontal direction:
QR: Referred to as two-dimensional, because they carry information both vertically and horizontally.
Symbology 2 MAIN Types:
UPC (Universal Product Codes)
EAN (European Article Numbers also called International Article Numbers
There are various bar code types:
| Code 39 | common barcode type used for various labels such as name badges, inventory and industrial applications. ... The checksum character is a type of MOD43 |
|---|---|
| Code128 | Code 128 is a high-density linear barcode symbology defined in ISO/IEC 15417:2007. ... GS1-128 (formerly known as UCC/EAN-128) is a subset of Code 128 and is used extensively worldwide in shipping and packaging industries as a product identification code for the container and pallet levels in the supply chain. |
| GSI-128 (EAN 128) | Subset of Code 128 and is used extensively worldwide in shipping and packaging industries as a product identification code for the container and pallet levels in the supply chain. |
| UPCA | Universal Product Code. ... UPC (technically refers to UPC-A) consists of 12 numeric digits, that are uniquely assigned to each trade item. Along with the related EAN barcode, the UPC is the barcode mainly used for scanning of trade items at the point of sale, per GS1 specifications. |
| UPCe | |
| UCC 128 | The UCC-128 (GS1-128) label is a critical piece of the EDI puzzle. The labels can be applied to both pallet shipments and individual cartons. Each label has information about the origin, destination, and contents of the shipment. Additional information typically includes a PO number and carrier code (SCAC) |
| EAN-13 | The European Article Numbering System (EAN) is a superset of U.P.C. EAN-13 consists of 13 numbers. |
| EAN-8 | The European Article Numbering System (EAN) is a superset of U.P.C. EAN-8 and consists of 8 digits for small packages. |
| Interleaved 2 of 5 | Interleaved 2 of 5 (ITF) is a numeric-only barcode used for encoding pairs of numbers in a high-density barcode format like code 128-character set C. |
